Overview

Features

• Built with a heavy duty trigger gun for added durability
• Compact unit with manual pump
• Maximum portability for small jobs and spot cleaning
• Pressure relief valve for safety
• Viton seals for chemical compatibility
• Natural color tank for easy visibility of product levels
• Product level fill markings in gallons and liters
• Extra wide stability base

Specifications

• Power Type: Manual
• Chemical pickup type: draws from pre-mixed solution
• Number of products unit can draw from: one product
• Capacity: 1.3 gallons (5 Liters)
• Discharge line length/diameter: 6.5 ft (2m) hose, with 1/4 in. (6.4 mm) inside diameter
• Discharge wand/tip type: Polypropylene trigger handle with 65˚ fan tip
• Output Distance: 3-5 ft (0.9-1.5 m)
• Output Volume: 2.5 gal/min (9.5 l/min)
• Flow Rate*: 0.45 gal/min (1.7 l/min)
• Pump Seals: Viton
• Run Time from full tank**: Approx. 3 mins
• *Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings.
• ** Area covered and run time may vary based on humidity, air flow, and product used.
