AeroLEDs EVO IV Landing & Recognition Light Non TSO For Experimental Aircraft
MFR Model# 01-2120
Overview
| AeroSun EVO IV is a newly optimized version of our long-trusted AeroSun LED Landing/Recognition light. Now with 3X the performance, this versatile LED can be mounted virtually anywhere on the aircraft. AeroSun EVO IV comes standard with AeroLEDs’ signature Pulse (wigwag) functionality. The Pulse controller is fully integrated into the light and requires no external circuitry. This feature significantly increases recognition in daylight as well as light operations, aiding in collision avoidance and reduced bird strikes. In dual or quad light installations, while operating in wig-wag mode, this self-contained pulse function reduces load on the aircraft electrical system by 50%. *Optional mount sold separately. |
Features
- Power consumption: 48 watts max
- Color temperature – aviation white
- Built-in pulse mode
- Synchronization
- Versatile installation
- 30k hr MTBF
- Built-in thermal protection
- Aluminum/black anodized heat sink
- UV hardcoated polycarbonate lens
Specifications
| AeroSun EVO IV | |
|---|---|
| Part Number | 01-2120 |
| Voltage | 9-30 |
| Current | 3.4A at 14V - 1.7A at 28V |
| Power | 48 Watts |
| Wigwag | Yes |
| Synchronization | Yes |
| Lumens | 5,000 |
| Candela | 150,000 |
| Beam Profile | 15° x 15° |
| Length | 5" |
| Width | 2.3" |
| Depth | 1.8" |
| Weight | 9.6 oz |
Reviews
Verified Purchase
AeroLEDs Aerosun Landing And Taxi Light With Pulse Non-TSO 9-40V
I have an RV8, had the vans wing lights with a halogen bulbs, could hardly see to taxi much less adequate elimination to land. These LEDs are awesome! Bought mine with the mounting brackets, expensive but worth it. Brackets help to make the lights adjustable to aim . Solid 4 times brighter
Verified Purchase
AeroLEDs Aerosun Landing And Taxi Light With Pulse Non-TSO 9-40V
Lights were perfect! Easy to install and were bright and worked exactly as expected.
Verified Purchase
AeroLEDs Aerosun Landing And Taxi Light With Pulse Non-TSO 9-40V
I am very happy
Verified Purchase
AeroLEDs Aerosun Landing And Taxi Light With Pulse Non-TSO 9-40V
High quality lights,super bright with beautiful machine work on the housing! Aeroleds has fantastic customer service! I wish they included schematic in the box instead of needing to download it!
Verified Purchase
AeroLEDs Aerosun Landing And Taxi Light With Pulse Non-TSO 9-40V
Only compared it with my 130w halogen as installed in my RV6 outside the aircraft. The halogen is more yellow and more a concentrated spot. The Aeroled is bright blueish LED light, more towards a flood, but VERY bright.
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Per the manufacturer, the Aerosun Landing light is one light and you can use the wig-wag feature by hooking up the yellow wire that comes with the light.
Height 2.25", Width 5", Depth 1.5"
When the lights are in the wig-wag mode, the power load is reduced because the lights are on 50% of the time in while in the pulse mode. They could reduce the power consumption by just installing the pulse or wig-wag mode by connecting aircraft power to the yellow wire and not have the landing light mode (red wire) connected.
AeroLEDs recommends a 20 or 22 AWG wire when connecting the blue and green wires.
This is weatherproof and UV protected. The Aerosun is designed for outside use without a cover.
