Millennium Cylinder Power Assembly Kit Contents SL36006W-A21P For: O-360-B D; O-540-B
| Vendor Part Number | Quantity | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA631348-A3 | 1 | Major Overhaul Gasket Set (Inc. Intake Hoses) | 08-11300 | $502.00 | |
| SA646543-A1 | 1 | Major Overhaul Gasket Set (No Intake Hoses) | 08-11443 | $263.95 | |
| 642917-2 | 6 | Intake Hoses | 08-11415 | $36.50 | |
| SA633106 | 12 | Hydraulic Valve Lifter | 08-11336 | $206.95 | |
| SA646597-A1 | 1 | Main Bearing Set | 08-11469 | $1489.00 | |
| SA627693 | 24 | Rocker Arm Bushing | 08-11232 | $4.35 | |
| SA538684 | 6 | Connecting Rod Bushing | 08-11200 | $21.90 | |
| SA639580 | 4 | Counterweight Bushing | 08-11379 | $24.95 | |
| SA629004 | 8 | Counterweight Snap Rings | 08-11247 | $0.82 | |
| SA626140 | 12 | Connecting Rod Nuts | 08-11220 | $9.50 | |
| MS24665-227 | 12 | Connecting Rod Cotter Pins | MS24665-227 | $0.25 | |
| SA630742 | 4 | Camshaft Bolts | 08-11286 | $13.55 | |
| SA630692 | 4 | Crankshaft Bolts | 08-11285 | $15.50 | |
| MS35756-8 | 1 | Woodruff Keys | 08-10859 | $1.84 | |
| SA638172 | 4 | Magneto Drive Rubber Bushings | 08-00321 | $6.99 | |
| SA646460 | 6 | Exhaust Valves | 08-11436 | $508.00 | |
| SA631654 | 12 | Exhaust Valve Rotocoils | 08-11309 | $63.75 | |
| SA627731 | 24 | Valve Keepers | 08-11233 | $4.95 | |
| SA625958 | 24 | Valve Springs | 08-11216 | $13.50 | |
| SA625957 | 24 | Valve Springs | 08-11215 | $8.50 | |
| SA629690 | 6 | Piston Pins | 08-11259 | $141.95 | |
| SA3610-SC | 6 | Piston Rings (For Steel Barrel) | 08-11013 | $275.95 | |
| SA631991 | 12 | Rocker Shafts | 08-11316 | $58.95 | |
| SA501867 | 12 | Rocker Shaft Retaining Bolt Washer | 08-11096 | $2.99 | |
| SA531001 | 12 | Cylinder Hold Down Nuts | 08-11148 | $15.50 | |
| SA531003 | 36 | Cylinder Hold Down Nuts | 08-11149 | $10.50 | |
| SA530917 | 1 | Crankcase Nose Seal | 08-11146 | $60.75 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
Reviews
Cheaper than TCM and likely made by same people. Always replace.
Verified Purchase
Superior SA531003 Nut
Verified Purchase
Superior SA3610-Sc Ring Set Single Cylinder
Great nut.
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
Verified Purchase
Superior SA501867 Washer, Tab Lock
Verified Purchase
Cotter Pin Cor AN381-25-8
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
In stock, arrived promptly and well packaged. No issues noted during installation..
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
Verified Purchase
Superior SA626140 Nut
Verified Purchase
Superior SA530917 Seal Assembly Oil Crankshaft
Verified Purchase
Superior SA630692 Bolt
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
