AeroLEDs Pulsar 660 Strobe Lights TSO For Certified Aircraft
Overview
| The TSO certified Pulsar NSP (Navigation/Anti-collision Strobe/Position) lights are designed to be installed on the wingtips of an aircraft where the navigation (red and green) and position (white) lights can be seen to determine the direction of the aircraft. The Pulsar NSP is TSO-C30c Type I, Type II and Type III and is TSO-C96a Class II approved. |
Specifications
- Power: 52 Watts
- Voltage: 9-18VDC
- Weight: 6.6 oz
- Dimensions: 1.85″ x 4″ x 1.3″
Reviews
Nice Kit
Verified Purchase
AeroLEDs Pulsar Nsp Wingtip Navigation / Strobe / Position Light Pair FAA TSO 12V
Item was as advertised, had no problems with installation
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
The box will include the following:
- A right and left navigation, strobe and position light
- Two mount brackets
- Two set screws
- Two Molex connector kits
- White envelope with a CofC listing the TSO number and the serial numbers for each light
These lights when ordering the pair will include one green and one red and both will contain an Anti-collision strobe. Please refer to the installation manual in the 'Documents' tab for proper installation.
They require power from the aircraft but they would not require a power supply like a non LED strobe.
They are made in the USA. This set of lights does not have replaceable lenses.
The Pulsar NSP units have a single flash pattern. The dwell time for the flash is 0.190 Seconds, the off time is 1.27 Seconds and the total period is 1.46 seconds. The light has a 13% duty cycle.
PER AEROLEDS: We recommend that the customer maintain an 11 distance between the magnetometer and our lights per D0160 environmental tests requirements. We also recommend that they maintain a physical separation of the wire on the back of our lights and the wire that is connected to their magnetometer.
The wiring diagram recommends a separate breaker for the nav and strobe wiring. You could wire them to the same switch as long as they are on separate breakers.
Yes, these are FAA TSO approved for installation on certified aircraft.
You would need a ground, and three power wires for the nav, strobe and rear lights.
No, the installation instructions show them attaching to separate breakers.
