- Photo may represent series and not specific product
- SHARE
Millennium Cylinder Power Assembly Kit Contents SL36006W-A20P For: O-360-A C F G;AEIO-360-B H;Lo-360-A;Hio-360-B Ho-360-C;IO-360-B E M; O-540-A E G H;IO-540-C D N T AEIO-540-D
| Vendor Part Number | Quantity Needed for Install | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL72057A + | 1 | Seat, Intake | 08-11875 | $82.99 | |
| SL72058A + | 1 | Seat, Exhaust | 08-11876 | $81.75 | |
| MS20823-8D + | 1 | Elbow | 08-10815 | $46.50 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $18.50 | |
| SL-STD-1872 + | 2 | Helicoil | 08-12032 | $3.45 | |
| MS49005-2 + | 2 | Plug | 08-10863 | $2.35 | |
| SL31C-12 + | 2 | Stud | 08-03636 | $9.95 | |
| SL25C-9 + | 1 | Stud | 08-11713 | $11.50 | |
| SL66610 | 4 | Bushing | 08-11814 | $2.65 | |
| SL36006W-A20P | 1 | Cylinder | 08-11749 | $2273.00 | |
| SL13444-1 | 1 | Piston Pin And Plugs | 08-11595 | $160.75 | |
| MS13998-3 | 1 | Cap | 08-10803 | $12.50 | |
| MS13997-3 | 2 | Key | 08-10802 | $10.65 | |
| SL10077 | 1 | Valve Spring Seat | 08-11502 | $18.50 | |
| SL11795 | 2 | Spring | 08-11538 | $19.70 | |
| SL11800 | 2 | Spring | 08-11541 | $24.50 | |
| SL13323 | 1 | Valve Spring Seat | 08-11591 | $20.50 | |
| SL16475 | 1 | Valve Spring Seat | 08-11667 | $26.80 | |
| SL19001A | 1 | Valve, Exhaust | 08-11697 | $456.00 | |
| SL73938 | 1 | Key | 08-11922 | $152.80 | |
| SL65441 | 1 | Spring Seat | 08-11812 | $18.90 | |
| SL12272 | 1 | Lock Plate | 08-11568 | $1.84 | |
| SL71481 | 1 | Cylinder Base Seal | 08-03637 | $5.40 | |
| SL71973 | 1 | Gasket | 08-11872 | $1.92 | |
| SL75906 | 1 | Gasket, Rocker Box | 08-11983 | $3.45 | |
| SL13790A | 1 | Shaft, Rocker | 08-11603 | $39.50 | |
| SL12892 | 2 | Thrust Button | 08-11579 | $5.60 | |
| SL14995 | 1 | Spring | 08-11629 | $6.99 | |
| SL61247 | 1 | Cover, Rocker Box | 08-11788 | $45.70 | |
| SL74241A | 2 | Ring, Piston | 08-11934 | $73.75 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
