Millennium Cylinder Power Assembly Kit Contents SL36006N-A20P For: O-360-A C;O-540-A D E G;Ho-360-B; Hio-360-B IO-360-B; IO-540-C D N TIO-540-G
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL72057A + | 1 | Seat, Intake | 08-11875 | $82.99 | |
| SL72058A + | 1 | Seat, Exhaust | 08-11876 | $81.75 | |
| MS20823-8D + 1 | 1 | Elbow | 08-10815 | $46.50 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $18.50 | |
| SL-STD-1872 + | 2 | Helicoil | 08-12032 | $3.45 | |
| MS49005-2 + | 2 | Plug | 08-10863 | $2.35 | |
| SL31C-12 + | 2 | Stud | 08-03636 | $9.85 | |
| SL25C-9 + | 1 | Stud | 08-11713 | $11.50 | |
| SL66610 | 4 | Bushing | 08-11814 | $2.65 | |
| SL36006N-A20P 1 | 1 | Stud Assembly | 08-11745 | $2258.00 | |
| SL13444-1 | 1 | Piston Pin And Plugs | 08-11595 | $158.75 | |
| MS13998-3 | 1 | Cap | 08-10803 | $12.50 | |
| MS13997-3 | 2 | Key | 08-10802 | $10.50 | |
| SL10077 | 1 | Valve Spring Seat | 08-11502 | $18.50 | |
| SL11795 | 2 | Spring | 08-11538 | $19.50 | |
| SL11800 | 2 | Spring | 08-11541 | $24.50 | |
| SL13323 | 1 | Valve Spring Seat | 08-11591 | $20.50 | |
| SL16475 | 1 | Valve Spring Seat | 08-11667 | $26.50 | |
| SL19001A | 1 | Valve, Exhaust | 08-11697 | $450.00 | |
| SL73938 | 1 | Valve, Intake | 08-11922 | $150.80 | |
| SL65441 | 1 | Valve Spring Seat | 08-11812 | $18.90 | |
| SL12272 | 1 | Lock Plate | 08-11568 | $1.82 | |
| SL71481 | 1 | Cylinder Base Seal | 08-03637 | $5.35 | |
| SL71973 | 1 | Gasket, Intake | 08-11872 | $1.89 | |
| SL13790A | 1 | Rocker Shaft | 08-11603 | $38.90 | |
| SL12892 | 2 | Rocker Shaft Buttons | 08-11579 | $5.55 | |
| SL14995 | 1 | Spring | 08-11629 | $6.90 | |
| SL61247 | 1 | Cover, Rocker Box | 08-11788 | $45.50 | |
| SL74241A | 2 | Ring. Piston | 08-11934 | $72.75 | |
| SL73857A | 1 | Ring. Piston | 08-03694 | $82.85 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
Reviews
good value
Verified Purchase
Superior MS13997-3 Key
I’m happy!
Verified Purchase
Superior Exh Studs For Lycoming 0320 & 0290
Verified Purchase
Superior Exh Studs For Lycoming 0320 & 0290
Verified Purchase
Superior Lycoming Cylinder Base Seal 7
These are far superior to the Lycoming gaskets. They last longer, arent brittle and maintain there form better.
Verified Purchase
Superior SL71973 Gasket
Work as described
Verified Purchase
Superior MS49005-2 Plug
Verified Purchase
Superior Millennium Cylinder SL36006N-A20P Complete Assembly
In stock, quick shipping, and a 25month warranty- this a no brainer. This is the 2nd I’ve had to install this year due to exhaust valve leakage on my 700hr o-360. Planning on replacing the remaining 2 for a complete millennium top end.
Verified Purchase
Superior Millennium Cylinder SL36006N-A20P Complete Assembly
Parts are an identical match and fit.
Verified Purchase
Superior SL12272 Lock Plate
Shafts fit perfect on a 49 year old motor. Will be awesome when we fire it up.
Verified Purchase
Superior SL13790A Shaft, Rocker Valve
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Yes, this assembly comes with the piston and ring.
