UMA 2-1/4 Inch Electrical Oil Press Tach 0-130 PSI Rotax 912/914 2 1/4" Air Core (270° Sweep) |
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
This is the correct tach for your application. The white wire from the sender will go into pin 5 of the DB 9 connector. The red wire will go to pin 2 and the black wire will go into pin 8. You will then need a jumper from pin 2 to pin 1 which will be connected to power. Also a jumper from pin 8 to pin 9 which will then go to ground.
