Overview

Features

• Powerful 7.0-Amp Jigsaw – Top jigsaw amp rating.
• Variable speed - Dial sets maximum speed and accelerator trigger controls operating speed.
• Constant Response™ circuitry – Maintains desired speed for consistent performance and precision.
• Aluminum gearbox with insulated cover
• Toolless Blade-Change System – Fast insertion, blade ejection lever eliminates need to touch hot blade. Most secure jigsaw clamping system.
• Internal Precision Control - Precision-machined plunging system and low-vibration design for enhanced accuracy and extremely smooth operation.
• Large, sturdy die-cast foot with steel insert and on-board bevel wrench.
• Exclusive multi-directional blade clamp provides superior grip of T-shank blades. (JS470E does not accept U-Shank blades)
• Four orbital-action settings -Different blade strokes for smooth to aggressive cuts.
• Adjustable dust blower keeps cutting line clear.
• Ergonomic top handle with soft-grip areas for solid, comfortable grip.
• Ambidextrous lock-on button – For steady long cuts and user comfort and control.

Specifications

• Amperage - 7.0
• Bevel Angle Range - 45°
• Category - Jig Saws
• Cutting Capacity Soft Wood - 5-7/8"
• Cutting CapacityAluminum - 7/8"
• Cutting CapacityMild Steel - 3/8"
• Hertz - 60 Hz
• Manuals - JS470E, JS470EB (EN) #19210 (D#19210)
• Max. Bevel Cut - 45°
• No Load SPM - 500-3,100
• Rating - 120V
• Service Baretool Numbers - 3601E13010
• Serviceable - Yes
• Stroke Length - 1"
• Weight (lbs.) - 5.90
