Overview

Features

• Tune frequencies by airport and station type at the touch of a button
• Send frequencies directly from AF-5000 EFIS
• GPS-based reverse lookup of airport and station type for manually entered frequencies
• Vertical and horizontal versions
• Monitor your standby frequency with dual watch
• Fully backlit, auto-dimming controls
• One-touch flip-flop with remote trigger ability
• Transmit indicator
• Receive indicator with active/standby differentiation
• Stuck mic indicator with transmit time-out

Specifications

• Control Panel Dimensions: 3.53” (89.7mm) x 1.80” (45.7mm) x 1.27” (32.4mm), available in vertical and horizontal versions
• Transceiver Module Dimensions:: 7.34” (186.6mm) x 2.38” (60.45mm) x 1.51” (38.23mm)
• Control Panel: 5.6 oz (159 g)
• Transceiver Module: 12 oz (390 g)
• Power Input: 10-30 VDC
• Transmit Power: 6 Watts
