Icom A25C VHF Air Band COM Radio - Lithium Battery - 110v
MFR Model# A25C 86 USA
Overview
The A25C is a powerful air band handheld with 6 watts of power and an IP57 waterproof rating; weather cannot stop these radios. The handheld includes a large 2350mAh Li-ion battery, providing a long operating time. The easy-to-use interface and large 2.3-inch LCD display combine to provide stress-free programming and in-flight operation.
The A25’s large 2.3-inch LCD provides user-friendly, graphic screens. The day mode allows pilots to view the screen in direct sunlight and the night mode makes it easy to read in the dark. |
Features
- IP57 dust-protection and waterproof construction
- "Flip-flop" channel recall
- Smart battery with detailed battery status
- 121.5MHz emergency key
- Weather channels
- Priority watch
- VFO scan, memory-channel scan, priority scan
- ANL (Auto Noise Limiter) for noise reduction
- Side tone function
- Internal VOX capability
Specifications
| General | |
| COM | A25C COM channels |
| Frequency Coverage Tx Rx RX (Weather) | A25C 118.000-136.975 MHz 118.000-136.975 MHz 161.650-163.275 MHz |
| Channel spacing | 25/8.33 kHz |
| Type of emission | 6K00A3E, 5K60A3E, 16K0G3E (Weather) |
| Power supply requirement | 7.2 V DC (BP-288), 11.0 V DC (External DC Jack) |
| Current drain (approximately) Tx High Rx Max. audio/Stand-by | Less than 1.8 A Less than 500 mA/90 mA typ. |
| Antenna impedance | 50 Ω |
| Operating Temperature Range | –10°C to +60°C; 14°F to 140°F |
| Dimensions (W×H×D) (projections not included) | 58.9 × 148.4 × 31.8 mm; 2.3 × 5.8 × 1.3 in |
| Weight (approximately) | 340 g; 12.0 oz (with BP-288) |
| Transmitter | |
| Output power (at 7.2 V DC) | 6.0/1.8 W typical (PEP/carrier) |
| Audio harmonic distortion | Less than 10% (at 60% modulation) |
| Hum and noise ratio | More than 35 dB |
| Spurious emissions | More than 46 dB (Exclude fc±62.5 kHz for AM mode) (Exclude fc±20.825 kHz for AM-N mode) |
| Frequency stability | ±0.4 kHz |
| Receiver | |
| Intermediate frequencies 1st 2nd | 46.35 MHz 450 kHz |
| Sensitivity (typ) COM (6 dB S/N) WX (12 dB SINAD) | Less than 0 dBμ Less than –8 dBμ |
| Squelch sensitivity (at threshold) | Less than 0 dBμ (AM), Less than –5 dBμ (FM) |
| Audio output power | More than 350 mW typ. (8 Ω load/60% Mod. at 10% distortion) |
| Hum and noise | More than 35 dB (at 30% modulation) |
| Spurious response | More than 60 dB (AM), More than 30 dB (FM) |
| Audio output power | More than 350 mW typ. (8 Ω load/60% Mod. at 10% distortion) |
| Ext. speaker connector | 3-conductor 3.5 (d) mm (1⁄8ʺ)/8 Ω |
Documents
In The Box
- Antenna
- Belt Clip
- Handstrap
- Battery Pack
- Headset Adapter
- Power Adapter
- Battery Charger
Reviews
Recently purchased this radio. Comes with a Basic Manual but recommend downloading the Full Manual from ICOM. Also the radios VOX was set to transmit automatically over the air even if I was just talking with a passenger using the intercom. Heard hot mike several times. The Full Manual shows the steps on setting VOX to off.
Excellent product .Would buy again for sure .
Verified Purchase
Icom A25C VHF Air Band Transceiver 110V Communication Only
The product met my high standards for quality and use. I am very satisfied with the technical aspects and would recommend this transceiver for other customers.
Verified Purchase
Icom A25C VHF Air Band Transceiver 110V Communication Only
Just purchased the A25c . Audio is far superior to my other radio with my old A-20 headset , all that you need is a PTT . Everything else is included . Great radio !
Bought the ICOM A25C for my husband. He is very pleased, and the radio is very clear. Thank you to Spruce aircraft for their helpful advice.
A great radio that is easy to use. I was pleasantly surprised to find the charger is multi-voltage as I will be using the radio in 110V and 240V countries. It was also a surprise to find a separate battery pack for AA batteries included.
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
The A25C is comm only, meaning that it is for communication only does not have NAV features. The A25N is a NAV/COM, meaning that it has communication and VOR navigation built in.
If the headset is a dual GA headset, it will work with the included headset adapter.
The manufacturer does not recommend using this while it is charging.
The voltage of the charger. 110v is the standard in North America. 220v is used in Europe.
There is not an included AA battery case, however, one is available as an option, 11-16396. That takes 6 AA batteries, however, no specific data is available regarding lithium vs alkaline for the tray.
Part # 11-15468 rapid charger for the IC A25C. (See Accessories)
