Start Pac Portable Unit - 28V Li2800 Qc
Overview
|
This unit is a full 28VDC battery pack and will provide superior startson all electrically-started turbine engines. It has dual, redundant chargers with a total of 7 amps output and a recharge time of approximately 4 hours.
The Start PacŪ Model Li2800 QC utilizes the latest technology in Lithium batteries. These batteries provide the same power as the lead-acid type but are 42% lighter and 32% smaller. These superior batteries provide the same power as the lead acid type, but have twice the cycle life and no sulfation issues. Note: This unit is designed for engine starting only. Note: Lithium ion batteries can be damaged by deep discharges. Do not run the batteries down below 23 volts, a spike during a start is okay. Voltages below 23 begin the damage to the batteries. At 18 volts, the batteries will be damaged beyond repair.. |
Features
- Twice the battery life of lead-acid batteries
- No sulfation problems (can be left in a completely discharged state without causing damage)
- Batteries have no memory effect and can be recharged at anytime.
- Made in the USA.
Specifications
- 28 AMP hours @ 10 Hour Rate
- 2400 AMPS Peak Current
- L 19.2" x W 7.5" x H 9.75" / L 48.768cm x W 19.05cm x H 24.765cm
- 46 lbs./20.8 kg Complete weight with built in charger and aircraft cable
- Not to be used as an aircraft battery charger.
- Do not charge in flight.
- Replacement Battery
- Quick Change replacement battery box for Li2800QC START PAC or Li2800QC Twin Pack 28V
- 8VDC safe Lithium-Ion
- 31 Ah capacity
- 2400A peak current
- 31.4lbs / 14.2kg
Benefits
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Yes, this unit is considered Hazardous. Product will be drop shipped. Supplier will ship FEDEX Ground only.
Yes, this unit is considered Hazardous. Product will be drop shipped. Supplier will ship FEDEX Ground only.
This does not show an expiraton date. If the batteries fall below 23 volts the batteries will start to be damaged and below 18 they will be beyond repair.
