Millennium Cylinder Power Assembly Kit - SL54002Nlc-A21P For: TIO-540-A1A A1B A2A A2B A2C
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL66713A + | 1 | Guide, Intake | 08-11816 | $41.70 | |
| SL71894A + | 1 | Seat, Intake | 08-11867 | $39.50 | |
| MS20823-6D + | 1 | Elbow | 08-10813 | $20.70 | |
| MS21209-C4-15 + | 4 | Helicoil | 08-10818 | $1.76 | |
| SL-STD-1872 + | 2 | Helicoil | 08-12032 | $3.45 | |
| SL10450 + | 1 | Fin Stabilizer | 08-11513 | $17.50 | |
| SL10451 + | 1 | Fin Stabilizer | 08-11514 | $10.50 | |
| SL10452 + | 1 | Fin Stabilizer | 08-11515 | $14.50 | |
| SL31C-10 + | 3 | Stud | 08-11718 | $7.50 | |
| SL66610 + | 1 | Bushing | 08-11814 | $2.65 | |
| SL66670 + | 3 | Bushing | 08-11815 | $2.71 | |
| 2-107 + | 2 | Helicoil | 08-12035 | $6.80 | |
| MS49005-2 + | 2 | Plug | 08-10863 | $2.35 | |
| SL13444-1 | 1 | Piston Pin And Plugs | 08-11595 | $160.75 | |
| MS13997-3 | 2 | Key | 08-10802 | $10.65 | |
| MS13998-3 | 1 | Cap | 08-10803 | $12.50 | |
| SL11796 | 2 | Spring | 08-11539 | $25.80 | |
| SL11797 | 2 | Spring | 08-11540 | $20.70 | |
| SL13322 | 2 | Valve Spring Seat | 08-11590 | $21.90 | |
| SL13622 | 1 | Valve, Intake | SL13622 | $204.95 | |
| SL16475 | 1 | Valve Spring Seat | 08-11667 | $26.80 | |
| SL16740A | 1 | Valve, Exhaust | 08-11677 | $505.00 | |
| SL62388 | 1 | Cap | 08-11809 | $38.50 | |
| SL69532 | 1 | Valve Spring Seat | 08-11842 | $23.50 | |
| SL72050 | 2 | Key | 08-11873 | $19.85 | |
| SL66732 | 2 | Gasket | 08-11821 | $1.52 | |
| SL71450 | 1 | Gasket | 08-11858 | $4.35 | |
| SL71481 | 1 | Ring | 08-03637 | $5.40 | |
| SL71973 | 1 | Gasket | 08-11872 | $1.92 | |
| SL72711 | 1 | Gasket | 08-11897 | $4.35 | |
| SL15619 | 2 | Gasket | 08-11639 | $4.35 | |
| SL74241A | 2 | Piston Ring | 08-11934 | $73.75 | |
| SL73857A | 1 | Piston Ring | 08-03694 | $83.95 | |
| SL72626A | 2 | Rocker Shaft | 08-11896 | $35.99 | |
| SL72242 | 1 | Cover, Rocker Box | 08-11886 | $88.75 | |
| SL10545 | 1 | Piston | 08-11519 | $414.00 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
Reviews
good value
Verified Purchase
Superior SL66732 Gasket
good value
Verified Purchase
Superior MS13997-3 Key
good value
Verified Purchase
Superior SL72050 Lock, Valve
Good value
Verified Purchase
Superior SL16740A Valve, Exhaust (Rotor Type)
Verified Purchase
Superior Lycoming Cylinder Base Seal 7
These are far superior to the Lycoming gaskets. They last longer, arent brittle and maintain there form better.
Verified Purchase
Superior SL71973 Gasket
Work as described
Verified Purchase
Superior MS49005-2 Plug
Verified Purchase
Superior MS13998-3 Cap
Verified Purchase
Superior SL71973 Gasket
Verified Purchase
Superior SL71973 Gasket
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
