Fig. No. | Description | Style | Qty Req. | Part No. | Price | Buy |
---|---|---|---|---|---|---|
1 | Cover Cap | New | 1 | TW-63A | $29.50 | |
2 | Nut | Old | 1 | AN364-720 | $2.51 | |
2 | Nut | New | 1 | AN365-720 | $1.63 | |
3 | Lock Ring Pin | Old | 1/2 | TW-17 | $21.65 | |
3 | Lock Ring Pin | New | 1/2 | TW-60AB | $26.50 | |
4 | Lock Ring | Old | 1 | TW-16 | $102.75 | |
4 | Lock Ring | New | 1 | TW-57A | $94.99 | |
5 | Nut | Old/New | 3 | AN364-440 | $0.82 | |
6 | Steering Arm Assembly with Lock-Pin & Lock-Ring | New | 1 | TW-15A | $397.00 | |
7 | Bracket Assembly,1-1/4" | New | 1 | 06-16201 | $419.00 | |
7 | Bracket Assembly,1-1/2" | Old | 1 | 06-16102 | $440.00 | |
7 | Bracket Assembly,1-1/2" | New | 1 | 06-16202 | $382.00 | |
8 | Lock Pin | Old/New | 1 | TW-13 | $74.75 | |
9 | Steering Arm Spring | Old/New | 1 | TW-14 | $15.65 | |
10 | Lock Cover Plate | Old/New | 1 | TW-12 | $29.50 | |
11 | Screw | Old/New | 3 | MS35206-217 | $0.09 | |
12 | Cam | Old/New | 1 | TW-10 | $84.90 | |
13 | Screw | Old/New | 2 | AN501-10-4 | $0.57 | |
15 | Oilite Bearing | Old | 1 | TW-7 | $67.75 | |
15 | Oilite Bearing | New | 1 | TW-59A | $96.75 | |
16 | Cotter Pin | Old/New | 1 | AN380-3-3 | $0.21 | |
17 | Screw | Old/New | 3 | TW-A18 | $0.38 | |
18 | Hub Cap | Old/New | 1 | TW-27 | $78.75 | |
19 | Axle Nut | Old/New | 1 | AN320-8 | $4.35 | |
21 | Tiresolid, No Bearings | Old/New | 1 | TW-23 | $535.00 | |
21 | Tiresolid, w/Bearings | Old/New | 1 | TW-23A | $649.00 | |
22 | Bearing w/Washer | Old/New | 1 | TW-A15 | $66.75 | |
23 | Washer | Old/New | 1 | TW-28 | $5.35 | |
24 | Felt Seal | Old/New | 1 | TW-26 | $6.50 | |
25 | Retainer Washer | Old/New | 1 | TW-64 | $10.50 | |
25 | Solid Rubber | Old/New | 1 | 06-00093 | $400.00 | |
26 | Arm Assembly .375 Dia. (Pneumatic) | New | 1 | TW-58A-1 | $365.00 | |
26 | Arm Assembly .375 Dia. (Solid Rubber) | Old | 1 | TW-21-1 | $400.00 | |
27 | Axle | Old/New | 1 | TW-5 | $148.75 | |
28 | Axle/Sirclip Ring | Old/New | 1 | TW-6 | $18.65 | |
29 | Bearing | Old/New | 2 | TW-A7 | $266.95 | |
30 | Inboard Wheelhalf, w/Bearings | Old/New | 1 | TW-30 | $631.00 | |
33 | Outboard Wheelhalf | Old/New | 1 | TW-31 | $322.00 | |
34 | Washer | Old/New | 1 | TW-A6 | $2.51 | |
35 | Lock Washer | Old/New | 3 | AN935-516 | $0.12 | |
37 | Hub Cap | Old/New | 1 | TW-32 | $73.80 | |
38 | Hub Cap Sirclip Ring | Old/New | 1 | TW-33 | $15.75 | |
13 | Screw | Old/New | 2 | AN501-A10-4 | $0.57 |
Old Style (Pre 1976) has 3/4" Fork Shaft (SFS-P8 Pneumatic or SFS Solid Rubber) & New Style (Post 1976) has 7/8" Fork Shaft (SFS-P8A Pneumatic and SFSA Solid Rubber) |
Good quality
MAULE TAILWHEEL FELT TW-26
Good quality
MAULE SIRCLIP RING TW-6
as described
MACHINE SCREW MS35206-217
Part fit on my old J3 tailwheel. Press fit. Solid attach.
MAULE TAILWHEEL CAP TW-63A
Off the wall expensive
LOCK RING PIN PRE-1976
Way too expensive
MAULE LOCK RING TW-16
All good.
MAULE TW-59A BEARING 7/8 ID
Reasonably priced, good quality-
MAULE TW-59A BEARING 7/8 ID
The precision of this pin is critical to the operation of the locking ring. If the pin doesn’t fully engage the potential to go for a wild ride exists. Wear is typically the culprit -either a shortened pin or a score that hangs up travel in the slot. Thankfully ACS has these is stock to keep us flying.
MAULE TAILWHEEL LOCK PIN TW-13
Fit without reeming. I drilled a hole for the grease to go through
MAULE TW-59A BEARING 7/8 ID
