Lycoming At Overhaul Parts Replacement List - IO-540-K1A5 K1B5 K1E5 K1F5 K1G5 K1J5 And S1A5
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL73185-1 | 1 | Engine Gasket Set | 08-11908 | $561.00 | |
| SL3601-SC | 6 | Piston Rings | 08-11751 | $179.75 | |
| SL16740A | 6 | Exhaust Valves | 08-11677 | $515.00 | |
| SL66713A | 6 | Intake Guides | 08-11816 | $41.70 | |
| MS13997-3 | 12 | Exhaust Valve Retaining Rings | 08-10802 | $10.85 | |
| SL78290 | 12 | Hydraulic Plunger Assemblies | 08-12007 | $149.75 | |
| SL11575 | 6 | Bearing Inserts ( Main ) | 08-11526 | $168.75 | |
| SL12186 | 12 | Connecting Rod Nuts | 08-11567 | $7.50 | |
| SL-STD-2209 | 1 | Crankshaft Gear Bolt | 08-12038 | $30.50 | |
| SL71903A-A | 8 | Counterweight Bushings | 08-11870 | $19.50 | |
| SL78528 | 1 | Oil Pump Bodies | 08-12008 | $615.00 | |
| SL18109A-S | 1 | Oil Pump Gears | 08-11683 | $843.00 | |
| SL78528KIT | 1 | Oil Pump Kit Includes: 1 - SL78528, 1 - SL18109A-S | 08-12009 | $1372.00 | |
| SL15628 | 1 | Oil Seal Crankshaft | 08-11640 | $38.70 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $8.50 | |
| SL-STD-213 | 1 | Oil Seal Fuel Pump | 08-12036 | $13.99 | |
| SL-STD-208 | 1 | Oil Seal Vacuum Pump | 08-12033 | $16.50 | |
| SL12136 | 4 | Magneto Drive Cushions | 08-11566 | $8.50 | |
| SL53E19600 | 1 | Thermostatic Bypass Valves | 08-11771 | $553.00 | |
| SL71667 | 1 | Lock Plates Fuel Pump Idler | 08-11866 | $5.35 | |
| SL72078 | 2 | Lock Plates Cam Gear | 08-11879 | $8.65 | |
| SL73383 | 1 | Lock Plate | 08-11912 | $5.80 | |
| MS16625-2081 | 1 | Circlip | 08-10806 | $2.03 | |
| SL72344 | 4 | Cylinder Fin Stabilizers | 08-11892 | $9.95 | |
| SL72343 | 4 | Cylinder Fin Stabilizers | 08-11891 | $9.95 | |
| LW15473 (41234) | 1 | AC Diaphragm Fuel Pumps | 07-00705 | $1372.00 | |
| SL-STD-1821 | 6 | Engine Hoses Oil Drainback Cylinder | 08-12031 | $5.35 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
Documents
Reviews
Worked great. Remember to cut them to size to match your cylinders.
Verified Purchase
Superior SL3601-Sc Ring Set Single Cylinder
Good quality. Was about an inch shorter than the original oil return hose I was replacing. Still enough length to secure it properly though.
Verified Purchase
Superior Sl-STD-1821 Hose
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
installed, works as advertised.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
good value
Verified Purchase
Superior MS13997-3 Key
Good value
Verified Purchase
Superior SL16740A Valve, Exhaust (Rotor Type)
It helped with my oil temperature problem. The old one wasnt routing enough oil to the cooler.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
a good fit
Verified Purchase
62B26931 Lycoming Fuel Pump (High Pressure)
Perfect Fit
Verified Purchase
Superior SL15628 Seal,Crankshaft Assembly
Good Quality
Verified Purchase
Superior Sl-STD-2209 Screw, 5/16 - 24 X 1.75
