Lycoming At Overhaul Parts Replacement List - IO-720-A1A A1B C1B D1B Narrow Deck
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL75181-1 | 1 | Engine Gasket Set | 08-11959 | $1491.00 | |
| SL3601-SC | 8 | Piston Rings | 08-11751 | $173.75 | |
| SL13444-1 | 8 | Piston Pins SL | 08-11595 | $158.75 | |
| SL16740A | 8 | Exhaust Valves | 08-11677 | $499.00 | |
| SL66713A | Intake Guides | 08-11816 | $41.70 | ||
| MS13997-3 | 16 | Exhaust Valve Retaining Rings | 08-10802 | $10.50 | |
| SL78290 | 16 | Hydraulic Plunger Assemblies | 08-12007 | $144.75 | |
| SL11575 | 8 | Bearing Inserts (Main) | 08-11526 | $162.95 | |
| SL-STD-1791 | 4 | Camshaft Gear Attaching Bolts | 08-12030 | $23.50 | |
| SL-STD-2213 | 1 | Crankshaft Gear Bolt | 08-12039 | $24.95 | |
| SL71903A-A | 32 | Counterweight Bushings | 08-11870 | $18.90 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $8.50 | |
| SL-STD-208 | 1 | Oil Seal Vacuum Pump | 08-12033 | $15.90 | |
| SL-STD-213 | 1 | Oil Seals Fuel Pump | 08-12036 | $13.55 | |
| SL12136 | 4 | Magneto Drive Cushions | 08-11566 | $7.50 | |
| SL53E19600 | 4 | Thermostatic Bypass Valves | 08-11771 | $535.00 | |
| SL18639 | 1 | Lock Plate Crank Gear | 08-11684 | $3.65 | |
| SL72078 | 2 | Lock Plates Cam Gear | 08-11879 | $8.55 | |
| SL73383 | 1 | Lock Plate Generator Bracket | 08-11912 | $5.60 | |
| SL73817 | 2 | Lock Plate Mag Idler | 08-11918 | $3.70 | |
| SL72343 | 8 | Cylinder Fin Stabilizers | 08-11891 | $9.85 | |
| SL72344 | 8 | Cylinder Fin Stabilizers | 08-11892 | $9.60 | |
| SL-STD2180 | 8 | All Engine Hoses | 08-00311 | $13.50 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
Documents
Reviews
The correct Part for a 172K. Different than auto hose
Verified Purchase
Superior SlstD2180 Return Hose
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
installed, works as advertised.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
good value
Verified Purchase
Superior MS13997-3 Key
Good value
Verified Purchase
Superior SL16740A Valve, Exhaust (Rotor Type)
It helped with my oil temperature problem. The old one wasnt routing enough oil to the cooler.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
Its a short piece of rubber hose that far and away surpassed my expectations. I mean it was both short, AND rubber. Wow, what a genius combination! Highly recommended!
Verified Purchase
Superior SlstD2180 Return Hose
Does the job of holding the crank gear to the crank for about half the price of the Lycoming bolt.
Verified Purchase
Superior Sl-STD-2213 Screw
Perfect fit for my o235
Verified Purchase
Superior SlstD2180 Return Hose
Quality and good fit at a fair price.
Verified Purchase
Superior SlstD2180 Return Hose
