Lycoming At Overhaul Parts Replacement List - IO-540-K1A5D K1F5D K1G5D And K1J5D
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL13367 | 1 | Engine Gasket Set | 08-11592 | $651.00 | |
| SL3601-SC | 6 | Piston Rings | 08-11751 | $175.75 | |
| SL13444-1 | 6 | Piston Pins | 08-11595 | $160.75 | |
| SL16740A | 6 | Exhaust Valves | 08-11677 | $505.00 | |
| SL66713A | 6 | Intake Guides | 08-11816 | $41.70 | |
| MS13997-3 | 12 | Exhaust Valve Retaining Rings | 08-10802 | $10.65 | |
| SL78290 | 12 | Hydraulic Plunger Assemblies | 08-12007 | $146.75 | |
| SL11575 | 6 | Bearing Inserts ( Main ) | 08-11526 | $165.75 | |
| SL12186 | 12 | Connecting Rod Nuts | 08-11567 | $7.50 | |
AN8-14A | 1 | Crankshaft Gear Bolt | AN8-14A | $5.99 | |
| SL71903A-A | 4 | Counterweight Bushings | 08-11870 | $18.90 | |
| SL15628 | 1 | Oil Seal Crankshaft | 08-11640 | $37.95 | |
| SL-STD-208 | 1 | Oil Seal Vacuum Pump | 08-12033 | $16.50 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $8.50 | |
| SL13641 | 2 | Magneto Drive Cushions | 08-11602 | $4.35 | |
| SL53E19600 | 1 | Thermostatic Bypass Valves | 08-11771 | $542.00 | |
| SL10332 | 1 | Lock Plates | 08-11512 | $17.99 | |
| SL73383 | 1 | Lock Plates | 08-11912 | $5.70 | |
| SL72343 | 6 | Cylinder Fin Stabilizers | 08-11891 | $9.95 | |
| SL72344 | 6 | Cylinder Fin Stabilizers | 08-11892 | $9.75 | |
| LW15473 (41234) | 1 | AC Diaphragm Fuel Pumps | 07-00705 | $1345.00 | |
| SL-STD-1821 | 6 | Engine Hoses Oil Drainback Cylinder | 08-12031 | $5.35 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
