Description | Part Number | Price | Buy |
---|---|---|---|
Maule Tailwheel Cap Tw-63A | TW-63A | $29.60 | |
Nut, Elastic Stop MS21083N7 | AN364-720 | $2.54 | |
Nut, Elastic Stop AN365-720 | AN365-720 | $1.92 | |
Maule Lock Ring Pin Post 1976 | TW-60AB | $26.50 | |
Maule Lock Ring Tw-57 | TW-57A | $94.99 | |
Elas Stop Nut MS21083N04 | AN364-440 | $0.84 | |
Maule Tailwheel Steering Tw-15A | TW-15A | $402.00 | |
Maule Bracket Assembly Tw-22A 1-1/4 | 06-16201 | $419.00 | |
Maule Brackt Assembly Tw-22A 1-1/2 | 06-16202 | $382.00 | |
Maule Tailwheel Lock Pin Tw-13 | TW-13 | $74.75 | |
Maule Tailwheel Spring Tw-14 | TW-14 | $15.65 | |
Maule Tailwheel Plate Tw-12 | TW-12 | $29.60 | |
Machine Screw MS35206-217 | MS35206-217 | $0.10 | |
Maule Tailwheel Cam Tw-10 | TW-10 | $85.99 | |
Fillister Head Screw AN501-10-4 | AN501-10-4 | $0.57 | |
Maule Tw-59A Bearing 7/8 Id | TW-59A | $103.85 | |
Cotter Pin AN380-3-3 | AN380-3-3 | $0.22 | |
Maule Screw | TW-A18 | $0.38 | |
Maule Tailwheel Ref. # Tw-27 | TW-27 | $78.75 | |
Nut, Shear AN320-8 | AN320-8 | $4.35 | |
Maule Tire 6.50 X 2.50 # Tw-23 | TW-23 | $535.00 | |
Maule Tail Tire With Bear Tw-23A | TW-23A | $686.00 | |
Maule TW101 Wheel Bearing F350-12, Tw-3/A15 | TW-A15 | $69.75 | |
Maule Tailwheel Washer Tw-28 | TW-28 | $5.35 | |
Maule Tailwheel Felt Tw-26 | TW-26 | $6.95 | |
Maule Tailwheel Tw-64 Washer | TW-64 | $10.50 | |
Maule Fork With Axle Tw-58A-1 | TW-58A-1 | $365.00 | |
Maule Axle With Sirclip Tw-6 | TW-5 | $148.75 | |
Maule Sirclip Ring Tw-6 | TW-6 | $18.65 | |
Maule Cup & Cone Bearing | TW-A7 | $266.95 | |
Maule Inside Hb With Bearng Tw-30 | TW-30 | $631.00 | |
Maule Outside Hub Tw-31 | TW-31 | $322.00 | |
Maule Washer | TW-A6 | $2.51 | |
Washer MS35338-45 (AN935-516) | AN935-516 | $0.13 | |
Maule Tailwheel Tw-32 Hub Cap | TW-32 | $74.75 | |
Maule T-Wheel Tw-33 Sirclip | TW-33 | $15.95 |
Maule Tailwheel Parts List |
These are hardened steel cams. The first one we purchased broke into like a potato chip. The replacement was fine, but we were careful to tighten each screw equally back-and-forth until the final torque was achieved. Make sure you use proper filister head screws to fasten the cam to the tail wheel housing. Finally put a thin film of grease on the outside of the cam where the release roller slides over the cam.
Maule Tailwheel Cam Tw-10
The first one received snapped in half when installing. Apparently they are heat treated and I suggest you tighten screw evenly. Spruce replace the broken part quickly and hassle free.
Maule Tailwheel Cam Tw-10
Good quality
Maule Tailwheel Felt Tw-26
Good quality
Maule Sirclip Ring Tw-6
as described
Machine Screw MS35206-217
Part fit on my old J3 tailwheel. Press fit. Solid attach.
Maule Tailwheel Cap Tw-63A
All good.
Maule Tw-59A Bearing 7/8 Id
Reasonably priced, good quality-
Maule Tw-59A Bearing 7/8 Id
The precision of this pin is critical to the operation of the locking ring. If the pin doesn’t fully engage the potential to go for a wild ride exists. Wear is typically the culprit -either a shortened pin or a score that hangs up travel in the slot. Thankfully ACS has these is stock to keep us flying.
Maule Tailwheel Lock Pin Tw-13
Fit without reeming. I drilled a hole for the grease to go through
Maule Tw-59A Bearing 7/8 Id
