Overview

Features

• Fully Serviceable Battery Pack
• 3 to 4 Engine Starts Per Charge
• Transmits up to 28 kilowatts of power
• Smart Lithium Technology
• 3,000 to 4,000 starts – Time Before Overhaul
• Charge Port attaches to on-board auxiliary power supply
• Includes 120/220V 50/60hzs battery charger
• Short Circuit Protection
• Impact, water and chemical resistant polymer case

10AH Specs

• Weight: 10.6 lbs
• Load on GPU Connector: 36 lbs/foot
• Length: 17″
• Width: 6.25″
• Height: 3″
• Capacity: 9.7 Ah
• Capacity (lead acid equivalent): 19.4 Ah
• Nominal Voltage: 26.4 Volts
• Max current (10 sec limit): 480 Amps
• Max current (Continuous): 200 Amps
• Max current (Protection off): 19400 Amps
• Max current (Protection on): 1350 Amps
• Operating Temperature: -30 to 60 deg C
• AC Charger Input Voltage: 110/240 Volts
• In-Flight Charge Circuit Rating: 5 Amps
• Charge Rate (software regulated): 3.5 Amps
• Number of starts per charge: 4-Mar
• Time before discharge: 29 minutes
• Charge Cycles: >1,000
• Engine Starts: 3,000 – 4,000
• Charge Time (after one start): 25-35 minutes
• Charge Time (dead battery): 2.8 hours
• State of Charge Indicator: Yes
• UNDOT Tested: Yes
• Injection Molded Case: Yes
• Emergency Start: Yes
• Ground Operations: Yes
• Database Updates: Yes
• On-Board Charger: Yes
• Fully Sealed: Yes
• Automatic Shut-off: Yes
• High Rate Charging: Yes
• Military Grade: No

15AH Specs

• Weight: 14.9 lbs
• Load on GPU Connector: 70 lbs/foot
• Length: 21.21″
• Width: 6.25″
• Height: 3″
• Capacity: 14.7 Ah
• Capacity (lead acid equivalent): 29.4 Ah
• Nominal Voltage: 26.4 Volts
• Max current (10 sec limit): 720 Amps
• Max current (Continuous): 300 Amps
• Max current (Protection off): 38800 Amps
• Max current (Protection on): 1350 Amps
• Operating Temperature: -30 to 60 deg C
• AC Charger Input Voltage: 110/240 Volts
• In-Flight Charge Circuit Rating: 5 Amps
• Charge Rate (software regulated): 3.5 Amps
• Number of starts per charge: 4-Mar
• Time before discharge: 44 minutes
• Charge Cycles: >1,000
• Engine Starts: 3,000 – 4,000
• Charge Time (after one start): 25-35 minutes
• Charge Time (dead battery): 4.2 hours
• State of Charge Indicator: Yes
• UNDOT Tested: Yes
• Injection Molded Case: Yes
• Emergency Start: Yes
• Ground Operations: Yes
• Database Updates: Yes
• On-Board Charger: Yes
• Fully Sealed: Yes
• Automatic Shut-off: Yes
• High Rate Charging: Yes
• Military Grade: No

20 AH Specs

• Weight: 19.4 lbs
• Load on GPU Connector: 38.8 lbs/foot
• Length: 17.25″
• Width: 7.31″
• Height: 4.27″
• Capacity: 19.4 Ah
• Capacity (lead acid equivalent): 38.8 Ah
• Nominal Voltage: 26.4 Volts
• Max current (Pulse): 1600 Amps
• Max current (Continuous): 400 Amps
• Max current (Chemistry): 51733 Amps
• Operating Temperature: -30 to 60 deg C
• AC Charger Input Voltage: 110/240 Volts
• In-Flight Charge Circuit Rating: 5 Amps
• Charge Rate (software regulated): 3.5 Amps
• Number of starts per charge: 3 to 4
• Time before discharge: 60 minutes
• Charge Cycles: >1,000
• Engine Starts: 3,000 – 4,000
• Charge Time (after one start): 30-40 minutes
• Charge Time (dead battery): 5.6 hours
• State of Charge Indicator: Yes
• UNDOT Tested: Yes
• Injection Molded Case: Yes
• Emergency Start: Yes
• Ground Operations: Yes
• Database Updates: Yes
• On-Board Charger: Yes
• Fully Sealed: Yes
• Automatic Shut-off: Yes
• High Rate Charging: Yes
• Military Grade: No
