Type | Model | Outer Panel Thickness | Length | A | B | C | Part No. | Price | Buy |
---|---|---|---|---|---|---|---|---|---|
GA | 1271-3175 | .015 - .025 | .175 | .220 | .311 | .015 | GA3-175 | $10.50 | |
GA | 1271-200 | .026 - .050 | .200 | .220 | .311 | .015 | GA3-200 | $4.35 | |
GA | 1271-250 | .051 - .094 | .250 | .220 | .311 | .015 | GA3-250 | $2.67 | |
GA | 1271-4250 | .026 - .050 | .250 | .311 | .405 | .025 | GA4-250 | $3.35 | |
GA | 1271-4275 | .051 - .075 | .275 | .311 | .405 | .025 | GA4-275 | $2.87 | |
GA | 1271-4300 | .076 - .100 | .300 | .311 | .405 | .025 | GA4-300 | $11.50 | |
GA | 1271-5312 | .031 - .062 | .312 | .374 | .500 | .028 | GA5-312 | $3.35 | |
GA | 1271-5350 | .063 - .094 | .350 | .374 | .500 | .028 | GA5-350 | $4.35 | |
GA | 1271-5375 | .095 - .125 | .375 | .374 | .500 | .028 | GA5-375 | $4.35 | |
GA | 1271-6350 | .040 - .065 | .350 | .437 | .594 | .028 | GA6-350 | $7.50 | |
GA | 1271-6375 | .066 - .100 | .375 | .437 | .594 | .028 | GA6-375 | $9.70 | |
GA | 1271-6425 | .101 - .135 | .425 | .437 | .594 | .028 | GA6-425 | $5.60 | |
GA | 1271-7375 | .050 - .095 | .375 | .531 | -- | .040 | GA7-375 | $7.99 | |
GF | 1276-4125 | .015 - .025 | .125 | .311 | .405 | .025 | GF4-125 | $12.70 | |
GF | 1276-4150 | .026 - .050 | .150 | .311 | .405 | .025 | GF4-150 | $24.60 | |
GF | 1276-4175 | .051 - .075 | .175 | .311 | .405 | .025 | GF4-175 | $10.50 | |
GF | 1276-4200 | .076 - .100 | .200 | .311 | .405 | .025 | GF4-200 | $13.50 | |
GF | 1276-5175 | .031 - .062 | .175 | .437 | .500 | .028 | GF5-175 | $2.02 | |
GF | 1276-5225 | .063 - .094 | .225 | .437 | .500 | .028 | GF5-225 | $3.70 | |
GF | 1276-5250 | .095 - .125 | .250 | .437 | .500 | .028 | GF5-250 | $8.50 | |
GF | 1276-6250 | .066 - .100 | .250 | .437 | .594 | .028 | GF6-250 | $3.55 | |
GF | 1276-7250 | .050 - .095 | .250 | .531 | -- | .040 | GF7-250 | $7.99 |
A full grommet is used when protection of the hole is a definite consideration. It protects panel finish and reduces stud play. A tool is required for installation. The "GA" type full grommet is used with a protruding head stud, and the "GF" type with a flush head stud. |
