Solid Aluminum Rivets - Universal Head - AN470

From $31.50 to $193.75
Part No. Type Dia. x Length Qty./Lb.
Approx.
Price per. Lb Buy / Lbs
AN470A-3-2
1100 Soft3/32 x 1/84107$111.75
Quantity
AN470A-3-3
1100 Soft3/32 x 3/163485$112.90
Quantity
AN470A-3-4
1100 Soft3/32 x 1/43027$81.75
Quantity
AN470A-3-5
1100 Soft3/32 x 5/162675$79.75
Quantity
AN470A-3-6
1100 Soft3/32 x 3/82397$81.75
Quantity
AN470A-3-7
1100 Soft3/32 x 7/162171$73.80
Quantity
AN470A-3-8
1100 Soft3/32 x 1/21826$70.75
Quantity
AN470A-3-10
1100 Soft3/32 x 5/81576$52.75
Quantity
AN470A-3-12
1100 Soft3/32 x 3/41403$68.75
Quantity
AN470A-3-14
1100 Soft3/32 x 7/81386$68.75
Quantity
AN470A-3-16
1100 Soft3/32 x 11237$72.75
Quantity
AN470A-4-3
1100 Soft1/8 x 3/161734$67.75
Quantity
AN470A-4-4
1100 Soft1/8 x 1/41529$49.50
Quantity
AN470A-4-5
1100 Soft1/8 x 5/161367$44.55
Quantity
AN470A-4-6
1100 Soft1/8 x 3/81236$44.55
Quantity
AN470A-4-7
1100 Soft1/8 x 7/161128$40.50
Quantity
AN470A-4-8
1100 Soft1/8 x 1/21037$41.99
Quantity
AN470A-4-9
1100 Soft1/8 x 9/16960$44.80
Quantity
AN470A-4-10
1100 Soft1/8 x 5/8836$46.50
Quantity
AN470A-4-12
1100 Soft1/8 x 3/4740$49.50
Quantity
AN470A-4-13
1100 Soft1/8 x 13/16715$138.75
Quantity
AN470A-4-14
1100 Soft1/8 x 7/8689$65.85
Quantity
AN470A-4-16
1100 Soft1/8 x 1594$41.55
Quantity
AN470A-4-20
1100 Soft1/8 x 1-1/4521$55.75
Quantity
AN470A-4-22
1100 Soft1/8 x 1-3/8496$67.90
Quantity
AN470A-5-4
1100 Soft5/32 x 1/4888$44.55
Quantity
AN470A-5-5
1100 Soft5/32 x 5/16850$38.90
Quantity
AN470A-5-6
1100 Soft5/32 x 3/8802$46.50
Quantity
AN470A-5-7
1100 Soft5/32 x 7/16672$40.50
Quantity
AN470A-5-8
1100 Soft5/32 x 1/2621$41.55
Quantity
AN470A-5-9
1100 Soft5/32 x 9/16578$44.55
Quantity
AN470A-5-10
1100 Soft5/32 x 5/8507$44.95
Quantity
AN470A-5-12
1100 Soft5/32 x 3/4407$54.75
Quantity
AN470A-5-16
1100 Soft5/32 x 1366$70.75
Quantity
AN470A-5-22
1100 Soft5/32 x 1-3/8314$63.75
Quantity
AN470A-6-4
1100 Soft 3/16 x 1/41134$41.55
Quantity
AN470A-6-5
1100 Soft3/16 x 5/16515$44.55
Quantity
AN470A-6-7
1100 Soft3/16 x 7/16436$38.55
Quantity
AN470A-6-8
1100 Soft3/16 x 1/2395$39.50
Quantity
AN470A-6-91100 Soft3/16 x 9/16354$38.55
Quantity
AN470A-6-10
1100 Soft3/16 x 5/8334$39.50
Quantity
AN470A6-12
1100 Soft3/16 x 3/4--$40.70
Quantity
AN470A-6-14
1100 Soft3/16 x 7/8299$40.50
Quantity
AN470AD-2-5
2117 Hard----$193.75
Quantity
AN470AD-3-2
2117 Hard3/32 x 1/84107$105.75
Quantity
AN470AD-3-3
2117 Hard3/32 x 3/163485$99.75
Quantity
AN470AD-3-4
2117 Hard3/32 x 1/43027$91.75
Quantity
AN470AD-3-5
2117 Hard3/32 x 5/162675$96.75
Quantity
AN470AD-3-6
2117 Hard3/32 x 3/82397$90.75
Quantity
AN470AD-3-7
2117 Hard3/32 x 7/162171$81.75
Quantity
AN470AD-3-8
2117 Hard3/32 x 1/21826$65.75
Quantity
AN470AD-3-9
2117 Hard3/32 x 9/16$65.75
Quantity
AN470AD-3-10
2117 Hard3/32 x 5/81576$53.95
Quantity
AN470AD-3-12
2117 Hard3/32 x 3/41403$70.75
Quantity
AN470AD-3-14
2117 Hard3/32 x 7/81386$93.75
Quantity
AN470AD-3-15
2117 Hard3/32 x 5/161383$179.75
Quantity
AN470AD-3-16
2117 Hard3/32 x 11237$103.85
Quantity
AN470AD-4-2
2117 Hard1/8 x 1/81838$58.75
Quantity
AN470AD-4-3
2117 Hard1/8 x 3/161734$64.75
Quantity
AN470AD-4-4
2117 Hard1/8 x 1/41529$60.75
Quantity
AN470AD4-4.5
2117 Hard1/8 x 9/321925$44.70
Quantity
AN470AD-4-5
2117 Hard1/8 x 5/161367$51.75
Quantity
AN470AD4-5.5
2117 Hard1/8 x 11/321674$44.55
Quantity
AN470AD-4-6
2117 Hard1/8 x 3/81236$43.50
Quantity
AN470AD-4-7
2117 Hard1/8 x 7/161128$39.50
Quantity
AN470AD-4-8
2117 Hard1/8 x 1/21037$53.75
Quantity
AN470AD-4-9
2117 Hard1/8 x 9/16960$45.50
Quantity
AN470AD-4-10
2117 Hard1/8 x 5/8836$40.50
Quantity
AN470AD-4-11
2117 Hard1/8 x $47.60
Quantity
AN470AD-4-12
2117 Hard1/8 x 3/4740$44.55
Quantity
AN470AD-4-13
2117 Hard1/8 x 13/16715$49.50
Quantity
AN470AD-4-14
2117 Hard1/8 x 7/8689$50.60
Quantity
AN470AD-4-15
2117 Hard1/8 x 5/16$68.90
Quantity
AN470AD-4-16
2117 Hard1/8 x 1594$40.50
Quantity
AN470AD-4-20
2117 Hard1/8 x 1-1/4521$51.75
Quantity
AN470AD-4-22
2117 Hard1/8 x 1-3/8496$78.75
Quantity
AN470AD-5-3
2117 Hard1/8 x 3/16--$60.75
Quantity
AN470AD-5-4
2117 Hard5/32 x 1/4888$52.80
Quantity
AN470AD-5-5
2117 Hard5/32 x 5/16850$44.85
Quantity
AN470AD-5-6
2117 Hard5/32 x 3/8802$35.50
Quantity
AN470AD-5-7
2117 Hard5/32 x 7/16672$31.50
Quantity
AN470AD-5-8
2117 Hard5/32 x 1/2621$42.50
Quantity
AN470AD-5-9
2117 Hard5/32 x 9/16578$40.50
Quantity
AN470AD-5-10
2117 Hard5/32 x 5/8507$40.50
Quantity
AN470AD-5-12
2117 Hard5/32 x 3/4407$44.55
Quantity
AN470AD-5-13
2117 Hard5/32 x .812514$47.65
Quantity
AN470AD-5-16
2117 Hard5/32 x 1366$41.55
Quantity
AN470AD-5-22
2117 Hard5/32 x 1-3/8314$60.75
Quantity
AN470AD-6-4
2117 Hard3/16 x 1/41134$41.65
Quantity
AN470AD-6-5
2117 Hard3/16 x 5/16515$37.50
Quantity
AN470AD-6-6
2117 Hard3/16 x 3/8--$40.50
Quantity
AN470AD-6-7
2117 Hard3/16 x 7/16436$39.50
Quantity
AN470AD-6-8
2117 Hard3/16 x 1/2390$49.55
Quantity
AN470AD-6-9
2117 Hard3/16 x 9/16354$38.60
Quantity
AN470AD-6-10
2117 Hard3/16 x 5/8334$40.50
Quantity
AN470AD-6-14
2117 Hard3/16 x 7/8299$37.60
Quantity
AN470AD6-16
2117 Hard3/16 x 1292$38.70
Quantity
Subtotal $0.00
Add to Wishlist

Overview

"A" rivets are "soft". They are fabricated from 1100-grade aluminum and have a tensile strength of 16,000 PSI. "AD" rivets are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI. Prices below are for 1lb. quantities. Minimum order of 1/8 lb. (use qty .13). All rivets can be purchased in 1/4 lb. (use qty .25) and 1/8 lb. (use qty .13) packages. AN470 (MS20470) AN426 (MS20426).

10% Discount for 5 lbs of rivets or more (per PN).
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

I like getting my solid rivets from Aircraft Spruce, easy to order and they have so much great stuff.

Lynn V Verified Purchase

Solid Aluminum Rivets AN470A-4-6-

October 28, 2024

Just as advertised

Randy W Verified Purchase

Aluminum Rivet AN470A-4-7

October 23, 2024

Just as advertised

Randy W Verified Purchase

Solid Aluminum Rivets AN470A-4-6-

October 23, 2024

arrived on time in good condition

Curtis W Verified Purchase

Solid Aluminum Rivet MS20470Ad-3-4

October 19, 2024

Work as they should

Chris G Verified Purchase

3/16 X 1 Solid Rivet Hard

September 9, 2024

Work as they should

Chris G Verified Purchase

Solid Aluminum Riv MS20470Ad-5-22

September 9, 2024

What I ordered/expected, as advertised.

Lantz P Verified Purchase

MS20470AD4-6 Solid Aluminum Rivets

September 5, 2024

As advertised and swiftly delivered

Lasse L Verified Purchase

Solid Aluminum Rivets AN470A-3-14

August 29, 2024

Carl P Verified Purchase

MS20470A-5-10 Aluminum Rivets

June 25, 2024

Richard H Verified Purchase

Solid Aluminum Rivets AN470A-4-4

June 15, 2024

Q&A

Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Are the MS20470AD superceded by the AN470?

Actually, the AN number has been superceded by the MS number, but we use the AN because it has been the norm for so long. They both meet the same specifications.

Q: I am unable to find A470-5-8 rivets. I typed this no. into the search box, but O results were listed.

The correct number is AN470A-5-8. You are missing the N and A in your query.

Q: What is the difference between soft and hard?

A rivets are soft. They are fabricated from 1100-grade aluminum and have a tensile strength of 16,000 PSI. AD rivets are fabricated from 2117 aluminum and heat treated to the T4 condition. They have a shear strength of 26,000 PSI and a tensile strength of 38,000 PSI.

Q: Are the rivets anodized?

No. These are not anodized.

Q: Hi, what is the difference between a MS20470AD4-4A AND MS20470AD4-4S? What is the A vs S?

"A" would indicate that the rivet has and anodize coating. "S" indicates that it has a chemical surface treatment per MIL-C-5541.

Q: Is it possible to purchase smaller quantities of the item AN470AD-4-14? I dont need a pound I just need 20 pcs.

Yes, minimum purchase quantity is 0.13 lbs.
