Alpha Systems AOA I/O Module Enhancement (Flaps)
Select Model:
Non PressurizedPressurizedOverview
| The I/O module expands the Alpha Systems with the capabilities of up to four flap inputs; analog flap input, gear advisory, master brightness control, squat switch, and other inputs and outputs allowing the expansion for future upgrades with this system. The I/O module is plug and play with a required software upgrade to the display module. Comes with cables, I/O module and hardware. There are 3 different types of Flaps. Analog, Discrete and Reverse Analog. Call to purchase the right one for your plane. |
Specifications
- Complete Flaps Weight: Approximately .29 LBs / 4.7 oz
- Transmitter + Fuse Assy Weight: Approximately .2 LBs / 3.2 oz
- 20Ft of Cable Weight: Approximately 0.4375 LBs / .7 oz
- 1/8" Clamp Weight: Approximately 0.0375 LBs / .6 oz
- 1/16" Clamp Weight: Approximately 0.4375 LBs / .7 oz
- Bar Clamp Weight: Approximately 0.01875 LBs / .3 oz
Documents
- Flaps Calibration Guide (PDF)
- Flaps Set-Up Guide (PDF)
- Discrete Flaps Connection Schematic (PDF)
- Analog Flaps Schematic (PDF)
- Reverse Analog Flaps Schematic (PDF)
- Flaps Transmitter Guide (PDF)
- Flap Transmitter with Cable Clamp Diagram (PDF)
- Flaps Transmitter with Bar Clamp Diagram (PDF)
- Flaps Transmitter Diagram (PDF)
- Flaps Increasing Voltage with Extension Diagram (PDF)
In The Box
- Flaps Module
- AUX Cable
- Connector Kit
- Fuse Assembly
- 8ft of 24 awg 6 conductor cable
- Installation Instructions
