| Foam Type |
Density | Tkns. | Sheet Size | PN | Price/Sheet | Buy |
|---|---|---|---|---|---|---|
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 1/8" | 32" x 48" | 01-00158 | $35.50 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 1/4" | 32" x 48" | 01-12300 | $58.75 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3/8" | 32" x 48" | 01-12400 | $90.75 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 5/8" | 32" x 48" | 01-12500 | $132.75 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3/4" | 15" x 26" | 01-12600 | $31.65 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3/4" | 32" x 48" | 01-12700 | $126.75 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3/4" | 32" x 24" | 01-01197 | $62.75 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 1" | 32" x 48" | 01-12800 | $183.85 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 1-3/4" | 32" x 48" | 01-12900 | $244.95 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 2" | 48" x 96" | 01-12920 | $959.00 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 2" | 24" x 48" | 01-12910 | $239.95 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3" | 48" x 96" | 01-12940 | $1377.00 | |
| Divinycell (PVC) Type H45 | 3 Lb/Cu. Ft. | 3" | 24" x 48" | 01-12930 | $346.00 | |
| Divinycell (PVC) Type H100 | 6 Lb/Cu. Ft. | 1/4" | 42.1" x 42.5" | 01-01310 | $137.75 | |
| Divinycell (PVC) Type H100 | 6 Lb/Cu. Ft. | 1" | 6" x 10" | 01-13100 | $17.50 | |
| Divinycell (PVC) Type H100 | 6 Lb/Cu. Ft. | 1" | 10" x 12" | 01-13200 | $21.55 |
- JUMP TO
- Overview
- Reviews
- Q&A
- View in Catalog
Overview
Divinycell:
|
Reviews
As advertised, flexible.
Verified Purchase
H45 Divinycell 1/8 X 32 X 48
Diviny cell foam is a great rigid core material, I just needed a small piece of 1/4, but only large sizes with expensive shipping were available in 1/4. So I bought an available small piece of 3/4 and cut thinner on a bandsaw. Also easily cuts with a sharp knife.
Verified Purchase
H45 Pvc Foam 3/4X 16X24
This foam is rigid and made for fiberglass if over, this needs to be written in the description
Verified Purchase
H45 Pvc Foam 1/4X32X48
Verified Purchase
H45 Pvc Foam 3/4X32X48
Product is good quality, well packaged with no damage. Origionally had problems but customer service fixed everything.
Verified Purchase
H45 Pvc Foam 3/4X32X48
Great product
Verified Purchase
H45 Pvc Foam 3/4X 16X24
So far I have only worked with one sheet to form it for the body of a race car. The divinycell is a little tricky in thermoforming but not bad once you get a feel for it. It takes a little time to get enough heat into the material but you can burn the surface it you hold the heat gun on it too long. You can heat the material again if you need to adjust your bend. Highly recommend that you use a slurry of resin and micro balloons when applying the first layer of fabric as the part will be stronger and lighter.
Verified Purchase
H45 Pvc Foam 1/4X32X48
Very fast shipping’s to Germany, only four business days! ! Product like in description! Thank you very much!
Verified Purchase
H100 Pvc Foam 1 X 10 X 12
Great foam, works with epoxy and fillers. Easy to cut and shape.
Verified Purchase
H45 Pvc Foam 3/4X 16X24
The foam was exactly what I ordered, PVC foam with is fuel resistant and the material specified for building the strakes/fuel tanks for the Cozy MK IV. The foam was packed extremely well with wood to prevent damage. Aircraft Spruce always does a good job packing items to prevent damage in shipment.
Q&A
Please note, Aircraft Spruce Canada's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Canada assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
H45 foam core can be used in place of R45 foam, but any changes of the plans should be reviewed with other builders.
Yes, Divinycell can be cut and sanded to shape.
No, Divinycell is not to be cut with a hot wire. The only foam that we offer that can be cut with a hot wire is our styrofoam, small cell (example part # 01-09400) and large cell (example part # 01-37600).
The sizes we offer are stock sizes with max length of 48". We may be able to special order a custom size, but the minimum order may be 20 pieces or more. We would just need the exact material and size you need and we can submit a request for a quote. Please contact our sales department if you would like to look into a special order for custom sizes.
Divinycell foam can be vacuum bagged. Polyester, vinyl-ester and epoxies can be used on this foam without any damage to the foam.
The heat distortion temp is 250 degrees. 350 degrees is much higher and would most likely damage the foam.
Yes. It can be cut using a CNC.
There is not a specific epoxy adhesive to be used on this material. All the epoxy adhesives we offer would work fine. You may want to consult with others with the same project to see what others have used with success. T-88, G-Flex, Aeropoxy adhesives, are just a few we offer.
No, these are rigid and will break if we try to roll them.
This has passed the test of being submerged in High Octane Petroleum Spirit for 14 days.
